MY-100 High Speed Paper Straw Machine 3.8-13mm

MY-100 High Speed Paper Straw Machine: What It Produces

The MY-100 is a paper straw forming machine built for converting paper into finished drinking straws. According to the supplied specification, it handles straw outer diameters from 3.8 mm to 13 mm, which allows one platform to cover common beverage straw sizes as well as larger diameters used in food service and packaging applications. Buyers planning a paper straw line, or adding straw capacity alongside cup and food-packaging production, should review the machine configuration against their target straw sizes, paper supply and required output before ordering.

Sample Display

Control and Cutting Configuration

The machine uses a PLC controller with a touch screen human-machine interface, so operating parameters can be set and adjusted from the panel. The main motor is fitted with variable frequency speed regulation, which supports speed adjustment during production. The cutting section combines a numerical multi-blade cutting system with a servo synchronous tracking cutting system; the servo tracking is intended to improve cutting precision, while the multi-blade arrangement is intended to raise cutting efficiency.

Construction details also matter for food-contact production. The machine body and main spare parts are made of stainless steel rather than painted surfaces, which supports hygiene and environmental protection of the finished product. Buyers should confirm the exact material grade and food-contact-relevant surfaces with the supplier for their market requirements.

Selection Variables to Confirm Before Quotation

Straw production covers a wide range of diameters, wall constructions and paper grades, so the machine configuration should be matched to the actual product rather than chosen from the model name alone. The following inputs help narrow the configuration:

Confirmed values for working speed, dimensions, weight, power and air requirements are listed in the Technical Specifications field of this page. Where a value is not stated there, treat it as to be confirmed with the supplier rather than assumed.

Where the MY-100 Fits in a Paper Packaging Line

Paper straws are usually one part of a broader disposable tableware or beverage packaging operation. If your project also includes paper cups, plates or die-cut blanks, review the related equipment scope so that material preparation, converting and packing stages are planned as separate steps rather than assumed to be integrated. Relevant references include the MY-970 automatic high speed roll die cutting machine for roll-fed blank preparation and the paper cup production solution overview for line-level planning.

For buyers comparing straw machine variants, the MY-100-A1 high speed paper straw machine is listed separately and can be reviewed alongside the MY-100 when matching diameter range and configuration to your product plan.

Project Preparation and Maintenance Notes

• Prepare straw drawings or physical samples with outer diameter, wall thickness and cut length before requesting a configuration.
• Confirm the paper grade, GSM and coating with your paper supplier, and share the specification for compatibility review.
• Plan for blade wear and cutting-section upkeep; the multi-blade cutting system is a wear part area that should be included in routine maintenance planning.
• Keep the touch screen panel and PLC cabinet in a clean, dry environment and follow the supplier's electrical and safety instructions.
• Confirm voltage, frequency and air supply against the site before shipment so that commissioning is not delayed.

Next Step: Send Your Straw Specification

To receive a matched configuration and quotation, send your target straw outer diameter and length, paper type and GSM, required output, voltage and frequency, air supply details, and workshop layout. The inquiry form on this page and the WhatsApp consultation option are the fastest routes to a response; our team will confirm which parameters are fixed and which remain configurable for your order.
