MY-50 Paper Straw Bending Machine: Sample and Working Scope

The MY-50 is a dedicated forming machine that converts straight paper drinking straws into flexible (bendable) drinking straws. It is intended for converters and food-packaging producers who already have a straight straw supply and want to add the bending step in-house rather than buying finished flexible straws. The machine is not a straw making line: it does not form the straw tube itself, so the straight straw specification, paper and coating must be matched before the machine configuration is fixed.

How the bending process runs

The working sequence is automatic once straight straws are loaded. An operator feeds straight straws into the machine; the machine then performs the bending and forming steps and discharges finished flexible straws. According to the supplied description, the only manual intervention in normal running is adding straight straws, which keeps labour input low and makes the unit suitable for continuous shift operation.

Built-in production controls

The machine includes automatic product counting. When the pre-set count is reached, an alarm sounds so the operator can pack the batch into bags at a consistent quantity. The machine also stops automatically when a fault occurs, which limits scrap and protects the tooling until the cause is checked. These two functions are the main reasons buyers choose this model for batch packing rather than loose collection.

Selection variables to confirm before quotation

Because the machine works on pre-made straight straws, the straw itself is the main selection variable. Please confirm the following with your inquiry so the configuration can be matched:

• Straight straw outer diameter and wall thickness, plus the finished straw length before and after bending.
• Paper type, coating (for example plain paper or coated paper) and nominal GSM of the straw wall.
• Target output and the batch count you want the counter set to for bag packing.
• Available power supply, voltage and frequency at the installation site.
• Workshop layout, including infeed and discharge space and how packed bags leave the machine.
• Whether the machine will run stand-alone or be linked to existing straw making or packing equipment.

Specifications and configuration boundaries

Confirmed model, working speed and other verified values are listed in the Technical Specifications field on this page. Values that are not confirmed in the source, such as exact supported straw diameter range, air consumption, installed power, machine dimensions, weight and packing method, should be confirmed with the supplier for your specific straw specification. Rated working speed is a machine figure; stable output in your plant will depend on straw quality, operator feeding and downstream packing.

Where this machine fits in a production plan

The MY-50 is a single-process unit, not a complete straw line. It is normally placed after straight straw production and before bag packing. If you are also planning cup or bowl production, the related equipment and line references can be reviewed alongside this machine, for example the paper cup machine range and the paper cup forming and packaging production line catalog.

Inquiry next step

To receive a matched quotation, send your straight straw sample or drawing, straw diameter and length, paper and coating details, target output, site voltage and frequency, and your packing requirement. Use the inquiry form on this page or contact us via WhatsApp with these details, and the configuration and remaining technical values can be confirmed against your straw specification.
